Laboratorio di Diffrattometria a Raggi X Cristallo Singolo

Referente
Fabrizio Nestola

Attività


Single-crystal X-ray diffraction is the most powerful experimental technique to determine the crystal structure of a crystalline compound. Therefore, it represents the first step to “explore” the  crystalline material properties.

RESEARCH FIELDS

  1. Compressibility.
  2. Physical properties of minerals.
  3. Crystal structure evolution under non ambient conditions.
  4. Determination of thermodynamic properties of feldspars, olivine, antigorite, clino and orthopyroxenes, garnets, spinels as a function of composition and pressure and their applications to geodynamics and geophysics of the Earth’s crust and mantle.
  5. Investigation of new mineral species.
  6. Identification and characterization of mineral inclusions in diamonds from upper and lower mantle. Develop of new experimental approach for measurements the inclusions in situ preserving the diamonds.
  7. Mineralogy of surface of Mercury from remote sensing acquisition in the Bepi Colombo ESA space mission.
  8. Structure solving of new MOF compounds.

Strumentazione

Gli strumenti presenti nel laboratorio sono:
- diffrattometro a 4 cerchi STOE STADI IV a rivelatore puntuale, operante con il software SINGLE (Angel and Finger, 2011) per misure ad elevata precisione;
- diffrattometro a 4 cerchi STOE STADI IV a rivelatore areale CCD (Oxford Diffraction) per determinazioni strutturali.
Il laboratorio dispone di 3 incudini di diamante tipo ETH (Zurigo), che permettono misure diffrattometriche in-situ ad altissima pressione per simulare le condizioni presenti nel mantello terrestre.
Il laboratorio è coinvolto in numerose collaborazioni nazionali e internazionali riguardanti la cristallografia di base e la cristallografia in condizioni estreme di pressione.


STOE STADI IV 4-circle diffractometer equipped with Mo source and point detector, operating with the SINGLE software (Angel and Finger, 2011) to perform high-accuracy and high-precision unit-cell parameter determination:

Point detector STOE STADI IV

Diffraction peak centered using SINGLE

Point detector STOE STADI IV

 Diffraction peak centered using SINGLE


STOE STADI IV 4-circle diffractometer equipped with Mo source and area detector CCD detector (Oxford Diffraction) suitable for rapid identification and structure determination:

CCD area detector STOE STADI IV

Diffraction pattern collected using a CCD detector

CCD area detector STOE STADI IV

 Diffraction pattern collected using a CCD detector

Three diamond anvil cells (DAC, ETH type) are available to perform in-situ high pressure measurements to reproduce in the laboratory the high-pressure conditions of the Earth’s mantle:



Diamond anvil cell (ETH type)

View through the diamonds into the DAC

Diamond anvil cell (ETH type)

View through the diamonds into the DAC

Sede

via G. Gradenigo, 6 - 35131 Padova (PD) - Tel. +39 049827 9110 - Fax +39 049 827 9134

Contatti

RESPONSABILE: Prof. Fabrizio Nestola - Tel. +39 049 827 9160 - Email: fabrizio.nestola@unipd.it

TECNICO ADDETTO: Dott.ssa  Daria Pasqual - Tel. +39 049 827 9136 - Email: daria.pasqual@unipd.it

Norme di accesso
PDF icon Accesso_cristallo singolo.pdf

Dettagli

L’accesso al Laboratorio di Diffrattometria Raggi X Cristallo Singolo è consentito esclusivamente in presenza del Responsabile Scientifico Prof. Fabrizio Nestola, o del Responsabile Tecnico dott.ssa Daria Pasqual.

Non è consentito l’uso delle attrezzature di laboratorio se non in presenza del Responsabile Scientifico e/o del Responsabile Tecnico. In ogni caso è necessaria la prenotazione

CALENDARIO PRENOTAZIONI DI ACCESSO AL LABORATORIO:

Per accedere al laboratorio è inoltre necessaria la presentazione della documentazione seguente:

1) Scheda di accesso

2) Attestato superamento corsi seguenti (solo al primo accesso):



PERSONALE ITALIANO:

FORMAZIONE SPECIFICA per ATTIVITA' A RISCHIO ALTO (Base 12 h)

FORMAZIONE SPECIALISTICA per il corretto utilizzo delle attrezzature del laboratorio e delle procedure di lavoro (Verbale di addestramento)


FOREIGN STAFF:

The course is for undergraduate, graduate, and Ph.D. students and any others who require access to the laboratories

GENERAL TRAINING (4 hours)

SPECIFIC TRAINING  (12 hours)

SPECIALISTIC TRAINING for the correct use of laboratory equipment and work procedures (Training report)




Richiesta prestazioni
PDF icon Prestazioni_cristallo singolo.pdf

Dettagli

Per informazioni su prestazioni e prezzi contattare il Prof. Fabrizio Nestola al recapito telefonico indicato nella pagina del laboratorio alla voce Contatti o inviare una mail all’indirizzo fabrizio.nestola@unipd.it
